BLG-02-SM-200
Shallow Bollards
The BLG-02-SM Shallow Bollard is a cutting-edge, fixed bollard engineered to provide maximum security in challenging urban environments. Specifically designed to counter the rising threat of vehicle-borne attacks, this bollard offers a robust defence against a wide range of threats.
Its shallow foundation of just 175mm makes it ideal for installation in areas with limited space, such as pedestrian zones, public squares, and commercial districts. Rigorously tested and rated with the highest industry standards, IWA 14-1:2013, the BLG-02-SM Shallow Bollard has proven its ability to withstand the impact of a 7,500 kg vehicle travelling at 48 km/h.
Built to Last
Crash tested to PAS68 for long reliable service in extreme conditions
Easy Installation
Precision engineering and manufacture for fast fitting and deployment
Custom Finishes
Choose between Stainless Steel or RAL colour powder coating
Key Features
- Crash-Tested: IWA 14-1:2013 V/7200[N2A]/48/90:0 – Rated as an array of 5
- Super Shallow Foundation – Only 175mm (6.9″) deep
- Height Above Road 1000mm / 39.37″
- Quick & Easy to install
- Available both as Fixed/Removable
- Tested Diameter: 220mm
- Bollard Diameter (D): 220mm/ 8.7″
- Bottom footprint: 1460mm(L)x 1000mm(W) – 57.48″ (L) x 39.37″(W)
- Protection Level: IWA 14-1:2013; V/7200[N2A]/48/90:0 (5 bollard-array)
- Unit weight: 310kg/683lbs
- Finish: Hot Galvanised, Powder coated, any RAL colour, Stainless steel cover
- Available: Removable option
Benefits
- Quick & Easy to install
- Super Shallow Foundation – Only 175mm deep
- Successfully tested to IWA14-1:2013 for a 7,200 kg vehicle travelling at 48 km/h.
- Available both as Fixed/Removable
- Hot dip galvanised, available in any RAL colour or Stainless steel. Optional: Reflective strip
- Maintenance Free
- Extreme versatility, suitable for all types of customers and sites
Additional Features
- Ideal for areas requiring high security
- High operational lifespan
- Impact test rated withstanding a 7,200 kg truck travelling at 48 km/h (30 mph).
- Ideal for urban areas and other high-density locations with vast underground infrastructure or limitations that hinder more traditional installations.
